AC Infinity IONFRAME EVO4 300W Lampa LED Grow Full Spectrum Samsung LM301H EVO do 120x120cm
The AC Infinity IONFRAME EVO4 300W is an advanced full-spectrum LED light equipped with 896 LEDs, including Samsung LM301H EVO LEDs with a rated efficiency of up to 3.14 µmol/J. It provides coverage of up to 120 × 120 cm during the vegetative stage and 90 × 90 cm during the flowering stage , with a maximum PPFD of 1,819 µmol/m²/s. It offers 10 brightness levels, a schedule, sunrise and sunset simulation , and integration with the AC Infinity UIS™ platform.
SecuritySSL encrypted website, Dutch dedicated server
Discreet shippingThere is no sender information on the package
Returns14 days to return without stating a reason
We are from Silesia! Buy and pick up in person in KatowiceQUICK ACCESS - CHECK THE MAP -
Średnia ocena: 4.6
Na podstawie: 85 ocen
Na podstawie: 85 ocen
AC Infinity IONFRAME EVO4 300W – Samsung LM301H EVO Full Spectrum LED Light
The AC Infinity IONFRAME EVO4 300W is an advanced Full Spectrum LED grow light designed for indoor plant cultivation. It utilizes high-efficiency Samsung LM301H EVO LEDs supplemented with 395 nm, 660 nm, and 730 nm LEDs. In total, the fixture features 896 LEDs, arranged in a bar-shaped design engineered to provide even light coverage across the growing area.
The lamp draws 300 W and is recommended for an area of 120 × 120 cm during the vegetative stage and 90 × 90 cm during the flowering stage. The maximum PPFD is 1,819 µmol/m²/s, and the Samsung LM301H EVO LEDs used have a rated efficiency of up to 3.14 µmol/J.
The IONFRAME EVO4 also stands out for its advanced control system. The included controller offers 10 brightness levels, a scheduling function, and sunrise and sunset simulation. The light is part of the AC Infinity UIS™ platform and is compatible with more advanced controllers, such as the Controller 69 PRO.
Samsung LM301H EVO – High-Performance LEDs
At the heart of the AC Infinity IONFRAME EVO4 are genuine Samsung LM301H EVO LEDs. The rated efficiency of a single LED is up to 3.14 µmol/J.
The design incorporates a total of 896 LEDs, including:
- 360 × Samsung LM301H EVO 3000K,
- 500 × Samsung LM301H EVO 5000K,
- 4 × Seoul 395 nm,
- 28 × OSRAM 660 nm,
- 4 × OSRAM 730 nm.
This combination creates a broad spectrum designed for use throughout the entire plant growth cycle—from the vegetative phase through flowering.
Full Spectrum – 3000K, 5000K, 395 nm, 660 nm, and 730 nm
IONFRAME EVO4 combines several light spectra in a single fixture. The 3000K and 5000K LEDs form the basis of the full spectrum, while additional wavelengths expand its characteristics.
- 3000K – the warm part of the white spectrum,
- 5000K – the cooler part of the white spectrum,
- 395 nm – an additional UV range,
- 660 nm – deep red,
- 730 nm – Far Red.
This allows a single lamp to be used during both the vegetative and flowering stages, without the need to change the main light source between the different stages of cultivation.
Coverage of 120 × 120 cm for the growth stage and 90 × 90 cm for the flowering stage
The AC Infinity IONFRAME EVO4 was designed primarily for medium-sized growing areas. The manufacturer specifies the recommended coverage as follows:
- 120 × 120 cm – vegetative phase,
- 90 × 90 cm – flowering phase.
The difference stems from the higher light intensity requirements during the flowering phase. On a 90 × 90 cm area, the full 300 W power can be concentrated over a smaller area.
Bar-style design and uniform light distribution
The IONFRAME EVO4 utilizes a design based on LED strips. The LEDs are arranged in a way designed to minimize the formation of brightly lit spots in the central area and improve light uniformity across the entire surface.
Spreading a large number of LEDs over a larger surface area of the fixture allows for more uniform lighting compared to a highly concentrated light source.
The dimensions of the entire lamp are 52 × 58 × 7.6 cm.
PPFD up to 1,819 µmol/m²/s
The maximum declared PPFD value for the AC Infinity IONFRAME EVO4 is 1,819 µmol/m²/s. Combined with a power output of 300 W and a large number of LEDs, this allows the light to be used as the primary light source in a properly selected grow box.
The actual PPFD value reaching the plants naturally depends on the lamp’s suspension height, the set power level, and the measurement location on the growing surface.
10 brightness levels
The kit includes a timer controller that allows you to adjust the lighting intensity. Users have 10 brightness levels at their disposal, eliminating the need to use the full 300 W power throughout the entire growth cycle.
The intensity can be gradually increased as the plants grow and adjusted to the current stage of cultivation.
Sunrise and sunset simulation
The IONFRAME EVO4 offers a gradual light fade-in and fade-out function. This allows for a smoother transition between light and dark periods rather than immediately turning on the lamp at a set intensity.
The sunrise and sunset simulation feature can be automatically executed according to a programmed schedule.
AC Infinity UIS™ and App Control
The lamp is part of the AC Infinity UIS™ ecosystem . When connected to a compatible advanced UIS controller, such as the Controller 69 PRO, it is possible to integrate the lighting with other AC Infinity equipment.
Proper UIS configuration provides access to Wi-Fi and AC Infinity app control, advanced schedules, automation, and grow recipes.
Removable SOSEN-320W LED driver
The IONFRAME EVO4 uses the SOSEN-320W LED controller. Its modular design allows you to remove the controller from the fixture and place it elsewhere.
Remote installation of the controller provides greater flexibility when organizing space and managing heat inside the grow box.
The lamp itself uses passive cooling, so it does not require additional fans mounted in the fixture.
Capable of daisy-chaining up to 80 lamps
The system also supports daisy-chaining multiple lamps. With the proper configuration, up to 80 LED lamps can be connected, allowing the IONFRAME series to be used in larger installations as well.
To create complex configurations, appropriate splitter keys—sold separately—may be required.
IP65 and a design optimized for indoor cultivation
The fixture has an IP65 rating. Its steel and aluminum construction is designed to operate in high-humidity environments typical of indoor cultivation.
The specified operating humidity range is 35–85% RH, while the operating temperature range is 0–60°C.
The declared system lifespan is 50,000 hours.
ETL Certification
The AC Infinity IONFRAME EVO4 complies with ETL standards for the safety of electrical equipment. The product is certified under ETL No. 5021417.
Key Features of the AC Infinity IONFRAME EVO4 300W
- power 300 W,
- 896 LEDs,
- Samsung LM301H EVO LEDs,
- rated LED efficiency up to 3.14 µmol/J,
- maximum PPFD 1,819 µmol/m²/s,
- Full Spectrum: 3000K + 5000K + 395 nm + 660 nm + 730 nm,
- coverage during the vegetative stage: 120 × 120 cm,
- coverage during the flowering stage: 90 × 90 cm,
- 10 brightness levels,
- programmable schedule,
- sunrise and sunset simulation,
- compatibility with AC Infinity UIS™,
- Wi-Fi and app control via a compatible UIS controller,
- SOSEN-320W controller,
- remote mounting option,
- passive cooling,
- daisy-chain capability for up to 80 lamps,
- IP65 rating,
- 50,000-hour lifespan,
- ETL certification No. 5021417.
AC Infinity IONFRAME EVO4 Technical Specifications
| ParameterValue | |
|---|---|
| Manufacturer | AC Infinity Inc. |
| Model | IONFRAME EVO4 / AC-IF4K |
| Power |
| 300 W |
| Main LEDs | Samsung LM301H EVO |
| Number of LEDs | 896 |
| Samsung EVO 3000K | 360 |
| Samsung EVO 5000K | 500 |
| Seoul 395 nm | 4 |
| OSRAM 660 nm | 28 |
| OSRAM 730 nm | 4 |
| Spectrum | 395 nm, 660 nm, 730 nm, 3000K, 5000K |
| Efficiency of a single diode | 3.14 µmol/J |
| Maximum PPFD | 1819 µmol/m²/s |
| Coverage – vegetative stage | 120 × 120 cm |
| Coverage – flowering | 90 × 90 cm |
| LED controller |
| SOSEN-320W |
| Brightness control | 10 levels |
| Controller | Schedule controller |
| Voltage | 100–277 V AC |
| Frequency | 50/60 Hz |
| Current | 3.0 A |
| Lamp dimensions | 52.0 × 58.0 × 7.6 cm |
| Controller dimensions | 18.2 × 4.0 cm |
| Protection rating | IP65 |
| Operating humidity | 35–85% RH |
| Operating temperature | 0–60°C |
| Service life | 50,000 hours |
| Certification | ETL No. 5021417 |
FAQ – AC Infinity IONFRAME EVO4 300W
What area is the AC Infinity IONFRAME EVO4 designed for?
The recommended coverage area is 120 × 120 cm during the vegetative stage and 90 × 90 cm during the flowering stage.
What LEDs are used in the IONFRAME EVO4?
The primary light source consists of Samsung LM301H EVO LEDs. The spectrum has been further expanded with Seoul 395 nm LEDs and OSRAM 660 nm and 730 nm LEDs.
How many LEDs does the AC Infinity IONFRAME EVO4 have?
The light has a total of 896 LEDs: 360 × EVO 3000K, 500 × EVO 5000K, 4 × 395 nm, 28 × 660 nm, and 4 × 730 nm.
What is the power of the IONFRAME EVO4?
The light has a power rating of 300 W.
What PPFD does the IONFRAME EVO4 achieve?
The maximum declared value is 1,819 µmol/m²/s PPFD. The actual level at a specific point on the surface depends, among other factors, on the suspension height and the set power.
Is the lamp suitable for growth and flowering?
Yes. The IONFRAME EVO4 offers a full spectrum covering 3000K, 5000K, 395 nm, 660 nm, and 730 nm, making it suitable for use throughout the entire growing cycle.
Does the AC Infinity IONFRAME EVO4 have adjustable power settings?
Yes. The included controller offers 10 levels of light intensity.
Does the lamp have a sunrise and sunset function?
Yes. The controller allows you to program a schedule and gradually brighten and dim the light, simulating sunrise and sunset.
Can the IONFRAME EVO4 be controlled via a smartphone?
Yes, when connected to a compatible UIS smart controller, such as the Controller 69 PRO, you can control it via Wi-Fi using the AC Infinity app.
Can the lamp controller be mounted outside the grow box?
Yes. The modular design allows you to detach the LED controller from the fixture and mount it remotely, which can help manage the temperature inside the grow space.
Is the IONFRAME EVO4 moisture-resistant?
The light has an IP65 rating and is designed for use in indoor growing environments.
What is the lifespan of the AC Infinity IONFRAME EVO4?
The declared lifespan is 50,000 hours.
